Hibernate ORM: Tips, Tricks, and Performance Techniques

Hibernate ORM:
Tips, Tricks, and
Performance Techniques
Brett Meyer
Senior Software Engineer
Hibernate ORM, Red Hat

Brett Meyer
• Hibernate ORM
– ORM 4 & 5 development
– Hibernate OSGi
– Developer community engagement
– Red Hat enterprise support, Hibernate engineering lead

• Other contributions
– Apache Camel
– Infinispan

• Contact me
– @brettemeyer or +brettmeyer
– Freenode #hibernate or #hibernate-dev (brmeyer)

github.com/brmeyer
/HibernateDemos

slideshare.net/brmeyer

ORM? JPA?
• ORM: Object/Relational Mapping
– Persistence: Data objects outlive the JVM app
– Maps Java POJOs to relational databases
– Supports OO concepts: inheritance, object identity, etc.
– Navigate data by walking the object graph, not the explicit
relational model

• JPA: Java Persistence API
• Hibernate ORM provides its own native API, in
addition to full JPA support
• Annotations and XML

Overview
•
•
•
•
•
•
•
•

Fetching Strategies
2nd Level Entity Cache
Query Cache
Cache Management
Bytecode Enhancement
Hibernate Search
Misc. Tips
Q&A

Caveats
• No “one strategy to rule them all”
• Varies greatly between apps
• Important to understand concepts, then
apply as necessary
• Does not replace database tuning!

First, the antithesis:
public User get(String username) {
final Session session = openSession();
session.getTransaction().begin();
final User user = (User) session.get( User.class, username );
session.getTransaction().commit();
return user;
}
public boolean login(String username) {
return get(username) != null;
}

Clean? Yes. But...

EAGER Demo
• Prototypes start “simple”
– EAGER
– No caching
– Overuse of the kitchen sink

• DAO looks clean
• Then you see the SQL logs

Fetching Strategies
• By far, the most frequent mistake
• Also the most costly
• 2 concepts:
– WHEN (fetch timing)
– HOW (fetch style)

Fetch Timing: EAGER
•
•
•
•

Immediate
Can be convenient (in some ways)
Significantly increases payload
Enormous amount of unnecessary
fetches for deep association tree

Fetch Timing: LAZY
• Fetched when first accessed
• Collections
– LAZY by default
– Utilizes Hibernate's internal concept of “persistent
collections”
– DEMO

• Single attribute (basic)
– Requires bytecode enhancement
– Not typically used nor beneficial

Fetch Timing: LAZY (cont'd)
• Single (ToOne) associations
– Fetched when accessed
– Proxy
• Default
• Fetched when accessed (except ID)
• Handled internally by Hibernate

– No-proxy
• Fetched when accessed (including ID)
• No visible proxy
• Requires buildtime bytecode enhancement

Fetch Timing: EXTRA LAZY
•
•
•
•

Collections only
Fetch individual elements as accessed
Does not fetch entire collection
DEMO

Fetch Style: JOIN
• Join fetch (left/outer join)
• Great for ToOne associations
• Multiple collection joins
– Possible for non-bags
– Warning: Cartesian product! SELECT is
normally faster

• DEMO

Fetch Style: SELECT
• Follow-up selects
• Default style for collections (avoids
cartesian products)
• Can result in 1+N selects (fetch per
collection entry)
• DEMO

Fetch Style: BATCH
• Fetches multiple entries when one is
accessed
• Configurable on both class and collection
levels (“batch-size”)
• Simple select and list of keys
• Multiple algorithms (new as of 4.2)
• Determines # of entries to fetch, based on
# of provided keys

Fetch Style: BATCH (cont'd)
• Legacy: pre-determined sizes, rounded
down
– batch-size==25, 24 elements in collection
– Fetches -> 12, 10, 2

• Padded: same as Legacy, size rounded up
• Dynamic: builds SQL for the # of keys,
limited by “batch-size”
• DEMO

Fetch Style: SUBSELECT
• Follow-up select
• Fetches all collection entries when
accessed for the 1st time
• Original root entry select used as
subselect
• Performance depends on the DB itself
• DEMO

Fetch Style: PROFILE
• named profile defining fetch styles
• “activated” through the Session

@Entity
@FetchProfile(name = "customer-with-orders", fetchOverrides = {
@FetchProfile.FetchOverride(entity = Customer.class,
association = "orders", mode = FetchMode.JOIN)
})
public class Customer {
...
@OneToMany
private Set<Order> orders;
...
}
Session session = ...;
session.enableFetchProfile( "customer-with-orders" );
Customer customer = (Customer) session.get(
Customer.class, customerId );

Fetch Style Tips
• Best to leave defaults in mappings
• Define the style at the query level
• Granular control

nd

2 Level Entity
Cache (2LC)

2LC
• differs from the 1st level (Session)
• SessionFactory level (JVM)
• can scale horizontally on commodity
hardware (clustered)
• multiple providers
• currently focus on Infinispan (JBoss) &
EHCache (Terracotta)

2LC (cont'd)
• disabled by default
– can enable globally (not recommended)
– enable for individual entities and
collections
– configurable at the Session level w/
CacheMode

• cache all properties (default) or only
non-lazy

2LC (cont'd)
• Since JVM-level, concurrency is an issue
• Concurrency strategies
– Read only: simplest and optimal
– Read-write
• Supports updates
• Should not use for serializable transaction isolation

– Nonstrict-read-write
• If updates are occasional and unlikely to collide
• No strict transaction isolation

– Transactional:
• Fully transactional cache providers (ie, Infinispan and EHCache)
• JTA required

Query Cache
• Caches query result sets
• Repetitive queries with identical params
• Different from an entity cache
– Does not maintain entity state
– Holds on to sets of identifiers

• If used, best in conjunction with 2LC

Query Cache (cont'd)
• Disabled by default
• Many applications do not gain anything
• Queries invalidated upon relevant
updates
• Increases overhead by some: tracks
when to invalidate based on commits
• DEMO

Cache Management
• Entities stored in Session cache when saved,
updated, or retrieved
• Session#flush syncs all cached with DB
– Minimize usage

• Manage memory:
– Session#evict(entity) when no longer needed
– Session#clear for all
– Important for large dataset handling

• Same for 2LC, but methods on
SessionFactory#getCache

Bytecode Enhancement
• Not just for no-proxy, ToOne laziness
• Reduced load on PersistenceContext
– EntityEntry
• Internally provides state & Session association
• “Heavy” operation and typically a hotspot (multiple Maps)

– ManagedEntity
• Reduced memory and CPU loads
• Entities maintain their own state with bytecode enhancement
• (ManagedEntity)entity.$$_hibernate_getEntityEntry();

– 3 ways:
• Entity implements ManagedEntity and maintains the association
• Buildtime instrumentation (Ant and recently Gradle/Maven)
• Runtime instrumentation

Bytecode (cont'd)
• dirtiness checking
– Legacy: “dirtiness” determined by deep comparison of
entity state
– Enhancement: entity tracks its own dirtiness
– Simply check the flag (no deep comparison)
– Already mentioned…
• Minimize amount of flushes to begin with
• Minimize the # of entities in the cache -- evict when possible

• Many additional bytecode improvements planned

Hibernate Search
• Full-text search on the DB
– Bad performance
– CPU/IO overhead

• Offload full-text queries to Hibernate
Search engine
– Fully indexed
– Horizontally scalable

• Based on Apache Lucene

Hibernate Search (cont'd)
• Annotate entities with @Indexed
• Annotate properties with @Field
– Index the text: index=Index.YES
– “Analyze” the text: analyze=Analyze.YES
•
•
•
•

Lucene analyzer
Chunks sentences into words
Lowercase all of them
Exclude common words (“a”, “the”)

• Combo of indexing and analysis == performant
full-text searches!

Misc. Tips
• Easy to overlook unintended fetches
– Ex: Fully implemented toString with all
associations (fetches everything simply for
logging)

• Use @Immutable when possible
– Excludes entity from dirtiness checks
– Other internal optimizations

Misc. Tips (cont'd)
• Use Bag or List for inverse collections, not Set
– Collection#add & #addAll always return true (don't
need to check for pre-existing values)
– I.e., can add a value without fetching the collection
Parent p = (Parent) session.load(Parent.class, id);
Child c = new Child();
c.setParent(p);
p.addChild(c);
...
// does *not* fetch the collection
p.getChildren().add(c);

Misc. Tips (cont'd)
• One-shot delete (non-inverse collections)
– Scenario: 20 elements, need to delete 18 & add 3
– Default: Hibernate would delete the 18 one-byone, then add the 3
– Instead:
• Discard the entire collection (deletes all elements)
• Save a new collection with 5 elements
• 1 bulk delete SQL and 5 inserts

– Important concept for large amounts of data

How to Help:
hibernate.org
/orm/contribute

QUESTIONS?
•
•
•
•

Q&A
#hibernate or #hibernate-dev (brmeyer)
@brettemeyer
+brettmeyer
